Alloy:1050/1060/1100/1070/3003/5052
Temper:HO-H24
Width:5-2600mm
Thickness:0.2-8.0mm
Coil ID：75mm, 150mm, 200mm, 300mm, 400mm, 508mm or customized
Coil OD:per customer’s request
Surface：Covering PVC film, embossing, mirror, anodizing, painting, wire drawing
Delivery Time：15-25 days
Certificated:ISO9001:2015,SGS,SABER
The raw material of the aluminum strip is pure aluminum or aluminum alloy cast rolled aluminum coil, hot rolled aluminum coil, by the cold rolling machine rolling into different thickness, width of the sheet aluminum coil, and then according to the use, by the slitting machine longitudinal cutting into different width of the aluminum strip.Our company commonly used specifications are available in stock, special size can be customized according to customer requirements.
Classification of aluminium strips
The alloy grades of commonly used aluminum belts are 1050, 1060, 1070, 1100, 3003, 3004, 5005, 5052, 8011 and so on.Common states are O state and H state, etc.O for soft, H for hard.O and H can be used after the number of soft and hard degree, and the degree of annealing.
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Other | Al | |
| Single | Total | ||||||||||
| 1050 | 0.25 | 0.4 | 0.05 | 0.05 | 0.05 | -- | 0.05 | 0.03 | 0.05 | 0.15 | 99.50 min |
| 1060 | 0.25 | 0.35 | 0.05 | 0.03 | 0.03 | 0.05 | 0.03 | 0.05 | 0.15 | 99.60 min | |
| 1100 | 0.95 | 0.05-0.20 | 0.05 | -- | -- | 0.1 | -- | 0.05 | 0.15 | 99.0min | |
| 3003 | 0.6 | 0.7 | 0.05~0.20 | 1.0~1.5 | -- | -- | 0.1 | -- | 0.05 | 0.15 | Remainder |
| 3105 | 0.6 | 0.7 | 0.3 | 0.30-0.8 | 0.20-0.8 | 0.2 | 0.4 | 0.1 | 0.05 | 0.15 | Remainder |
| 5052 | 0.25 | 0.4 | 0.1 | 0.1 | 2.2-2.8 | 0.15-0.35 | 0.1 | -- | 0.05 | 0.15 | Remainder |
| 5754 | 0.4 | 0.4 | 0.1 | 0.5 | 2.6-3.6 | 0.3 | 0.2 | 0.15 | 0.05 | 0.15 | Remainder |
| 6061 | 0.4-0.8 | 0.7 | 0.15-0.40 | 0.15 | 0.8-1.2 | 0.04-0.35 | 0.25 | 0.15 | 0.05 | 0.15 | Remainder |
| 6063 | 0.20-0.6 | 0.35 | 0.1 | 0.1 | 0.45-0.9 | 0.1 | 0.1 | 0.1 | 0.05 | 0.15 | Remainder |
1, aluminum coil strip corrosion resistance, not rust.Insulation aluminum coil strip is used in wet environment, such as power plant, chemical plant pipeline insulation, other insulation materials as aluminum coil strip corrosion resistance, short life, every few years need to be repeated construction once;Aluminum strip will not rust, long service life, a construction, you can benefit for many years, cost-effective.
2. The insulation aluminum coil strip belt has beautiful appearance.Compared with other insulation materials, aluminum coil silvery white metallic luster is very prominent, and can be maintained for a long time, with aluminum coil insulation construction, beautiful and generous.
3, the aluminum coil strip more value-preserving, waste aluminum can be recycled.Compared with other insulation materials, the recycling price of waste aluminum can reach more than 80% of the aluminum ingot price. Through waste aluminum recycling, manufacturers can recover most of the investment capital, which makes the thermal insulation aluminum coil strip become the most cost-effective insulation materials.
